Name: WNK Small Diameter 19mm Submersible Borehole Water Level Sensor for Deep Well
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK8010-19
Price: 42.00 USD
Availability: InStock

Do domu > produkty > Przetwornik poziomu wody >

WNK Small Diameter 19mm Submersible Borehole Water Level Sensor for Deep Well

19mm submersible water level sensor

deep well water level transmitter

small diameter borehole sensor

Miejsce pochodzenia:

Anhui, Chiny

Nazwa handlowa:

WNK

Numer modelu:

WNK8010-19

Skontaktuj się z nami

Poproś o wycenę

Szczegóły produktu

Gwarancja:

1 rok

Dostosowane wsparcie:

OEM, ODM

Zakres ciśnienia::

0 ... 2 ~ 200 metrów

Wyjście:

4-20MA, 0-5 V, 1-5 V, 0,5-4,5 V, 0-10 V

Dokładność:

0,2%FS, 0,5%FS,

Zasilacz:

12 ~ 36 V prądu stałego

Klasa ochronna:

IP68

Aplikacja:

Woda deszczowa, woda pitna, ścieki, ścieki, woda morska

Materiał mieszkaniowy:

304SS, 316L

Temperatura robocza::

-40~85 ℃

Typ:

Miernik

Usługa OEM:

OEM, ODM, dostępne dostosowanie

Port:

Szanghaj/Ningbo

Podkreślić:

19mm submersible water level sensor

deep well water level transmitter

small diameter borehole sensor

Warunki płatności i wysyłki

Minimalne zamówienie

1PCS

Cena

$35.00 - $50.00/Pieces

Szczegóły pakowania

Każdy ustawia się na jeden indywidualny karton, ochrona z pianki. Następnie w Master Carton

Czas dostawy

5-8 dni roboczych

Zasady płatności

T/T, Western Union, Moneygr, PayPal

Możliwość Supply

2000 sztuk/kawałków czujnik ciśnienia na poziomie miesięcznie

Produkty pokrewne

wideo

WNK ATEX Explosion Proof LCD Display Liquid Level Sensor With 4-20mA for Water Tank

Najlepszą cenę

wideo

WNK Small Diameter 19mm Submersible Borehole Water Level Sensor for Deep Well

Najlepszą cenę

wideo

WNK Submersible Hydrostatic Water Level Sensor Probe for River Tank Liquid Level Transmission Pressure Transmitter

Najlepszą cenę

wideo

316L Stainless Steel 4-20mA RS485 1-10V Liquid Level Transmitter Submersible Water Diesel Fuel Tank Level Sensors

Najlepszą cenę

Skontaktuj się z nami

Skontaktuj się teraz

Opis produktu

Product Description

Output	4-20mA, 0-5V, 1-5V, customization
Measured Range	0-0.5~200mH2O
Max overload	150% of sensor range
Pressure Type	Gage,Absolute
Accuracy	±0.2% FS/year
Long Term Stability	±0.25% FS/year
Housing Material	Stainless steel
Cable Material	Polyvinyl Fluoride, PTFE
Power supply	24V DC
Operating Temperature	-30~85℃
Compensation Temperature	-20~70℃
Protection Class	IP68

WNK8010-19 deep well water level sensor has high accuracy, small volume,stability,plus resistance to abrasion,oil,acid&alkali and high intensity gas lead cable ensured that it can meet the different occasions measurement requirements.

no-polarity two wire current output.

♦ It is widely used in well, standpipe, borewell, sewage, river and lakes treatment as well as channel, large rivers, l reservoirs and coastline monitoring.

♦ This product has got intrinsic safety certification,explosion proof certification and CE certification.

Applications

• Water tank level measurement and control.
• Fuel tank level measurement and monitor (diesel, gasoline, kerosene and so on).
• Liquid level measuring in tank, rivers, lake, sea, well, tube, underground water and so on.
• Special occasion such as high temperature liquid (up to 100 degree C), strongly corrosion liquid level measurement (request by customized.)

Features
• Adopting diffusion silicon oil-filled sensor
• Max measure range up to 200 meters or more
• High Stability, provide 0.1, 0.2, 0.5 accuracy for option
• Factory direct price

Size/Principle
